A Distributed Pipeline Formalization in Caelum

26 Sep 2026

This article describes how I used Caelum to formalize a lock protocol and verify that it prevents data corruption and deadlock.

The specification can be checked in the browser: NFS Shared Lock in the Caelum docs.

Context

A data pipeline runs across several machines and produces large volumes of data, so transferring data between machines must be avoided. The machine that produces a dataset is not the one that validates it, and validation may write files next to the data it checks.

All machines therefore mount the same NFS export as a shared scratch space. Before writing into a directory, a job locks it. Any job may read; writes happen only while holding the lock.

Requirements:

No data corruption. Two jobs never write to the same directory concurrently. If a defect causes two jobs to attempt it, one of them must fail loudly (wait or time out) instead of silently overwriting the other.
No deadlock. If a job crashes while holding the lock, the next run of that job must still be able to proceed.

How a lock becomes a consensus problem

A straightforward design evolves as follows:

A job creates a lock before writing and removes it afterwards.
If the holder crashes, the lock is never removed and the pipeline stops.
A common remedy is to break locks older than some threshold. However, a slow holder (swapping, blocked on I/O, paused VM) is indistinguishable from a dead one, so two jobs can end up holding the lock: the silent corruption the lock exists to prevent.
Preventing that requires heartbeats, leases, fencing tokens, and a service that issues the tokens; making that service fault tolerant requires several replicas that agree on its state.

At this point the design requires consensus. The underlying reason is that a remote observer cannot distinguish a crashed process from a slow one, which is the core of the FLP impossibility result. Any design in which one machine must decide that a process on another machine is dead leads to this problem.

The design presented here avoids it by not coordinating at all.

Assumptions that remove the problem

Two properties of this pipeline make coordination unnecessary:

Host affinity: a given job always runs on the same host.
Exact local failure detection: a host can determine with certainty whether one of its own processes is dead, by comparing boot id, pid, and process start time.

Consequently, a lock left by a crashed run of a job was created on the host where the job runs, and that host can verify the holder’s death exactly and recover the lock. A lock owned by another host is never judged remotely; the process waits, and the owning host recovers the lock.

The question “is that remote process dead?” is never asked, so no coordination is required. The only shared state is the lock on NFS, whose metadata records the owner’s machine-id, boot id, pid, and start time.

Let P, M, B, and T be the pid, machine-id, boot id, and start time recorded in the lock. The lock is stale if and only if:

M = current machine-id ∧
( no process has pid P ∨
  T ≠ start time of P ∨
  B ≠ current boot id )

If M ≠ current machine-id, the lock was acquired by a remote host, so the process waits or times out.

Formalization in Caelum

Caelum is an LTL model checker: a specification describes states, transitions, and properties, and Caelum checks the properties against every reachable state and every interleaving.

The model has two hosts and three processes: local runs two (so they can race to recover a crashed lock) and remote runs one. The host of each process is a static fact:

type Host = enum { local, remote }
let host[p ∈ Proc] ∈ Host

init {
  host[0] = local ∧
  host[1] = local ∧
  host[2] = remote
}

host[p] denotes the host where process p runs: host[0] = local states that process 0 runs on host local. Processes 0 and 1 share host local; process 2 runs on remote.

The rest of the state is st[p], the state of process p (free, waiting, or holding), and the lock on the shared filesystem: lock (unlocked, locked, or stale) and owner (the host recorded in its metadata).

Notation. A transition is one step of the system, written as a predicate over two states: the state before the step and the state after it. An unprimed name such as st[p] denotes the value before the step; the primed name st[p]' denotes the value after it. For example, st[p] = waiting ∧ st[p]' = holding means “p was waiting and is now holding”. Conjuncts over unprimed names form the guard (when the step is enabled); conjuncts over primed names form the effect (what the step changes). ∧ is conjunction and ∨ is disjunction.

unchanged(...) lists the variables that the transition does not modify: unchanged(x, y) abbreviates x' = x ∧ y' = y. A variable not constrained by a transition may take any value in the next state, so every variable the step must preserve is listed explicitly. except excludes one index of an indexed variable: unchanged(st except p) states that the state of every process is unchanged except that of p, the process performing the step.

The protocol is captured by the guard of acquire:

transition acquire(p ∈ Proc) {
  // p is waiting,
  st[p] = waiting ∧
  // the lock is free, or stale
  // and owned by p's host:
  (lock = unlocked ∨
    (lock = stale ∧ owner = host[p])) ∧
  // p now holds it,
  st[p]' = holding ∧
  // the lock is taken
  lock' = locked ∧
  // and records p's host;
  owner' = host[p] ∧
  // everyone else is untouched
  unchanged(st except p, host)
}

That is: a process may take the lock if it is free, or if it is stale and owned by the process’s own host. A holder leaves the critical section in one of two ways. Normally it releases the lock:

transition release(p ∈ Proc) {
  // p holds the lock,
  st[p] = holding ∧
  // finishes its work and exits,
  st[p]' = free ∧
  // removing the lock;
  lock' = unlocked ∧
  // nothing else changes
  unchanged(st except p, owner, host)
}

Alternatively it crashes, leaving a stale lock behind:

transition crash(p ∈ Proc) {
  // p holds the lock,
  st[p] = holding ∧
  // dies,
  st[p]' = free ∧
  // leaving the lock behind, stale,
  lock' = stale ∧
  // still naming p's host
  unchanged(st except p, owner, host)
}

The required properties talk about whole runs of the system, over time, using two temporal operators:

□ φ, always: φ holds in every state, from now on. □ (x ≠ 2) means “x is never 2”.
◇ φ, eventually: φ holds in some state, now or later. ◇ (x = 2) means “x will be 2 at some point”.

Combined, □ ◇ φ reads “φ holds infinitely often”: whatever happens, φ comes back. The liveness properties below use this form. ∀ p ∈ Proc: means “for every process p”, and → is implication.

// No data corruption:
// at most one holder.
property mutual_exclusion {
  □ (∀ p ∈ Proc: ∀ q ∈ Proc:
       (p ≠ q ∧ st[p] = holding) →
         st[q] ≠ holding)
}

// No deadlock: the lock is never
// stale forever.
property crash_recoverable {
  □ ◇ (lock ≠ stale)
}

// Progress: the lock keeps being
// taken; the pipeline never stalls.
property work_progresses {
  □ ◇ (lock = locked)
}

In the browser, Caelum checks these with bounded model checking and k-induction (using a SAT solver). The safety properties are proved for every reachable state; the liveness properties have no violating loop within 20 steps. Running caelum check --engine explicit enumerates all 44 reachable states and proves every property, liveness included.

Only the crash host can recover a stale lock (the guard of acquire), so crash_recoverable means the crash host eventually takes the lock back.

Per-process progress, □ (∀ p: waiting(p) → ◇ holding(p)), does not hold. A process that keeps crashing on one host and recovering its own stale lock can starve the processes on the other host: the lock is always either held or stale and owned by the other host, so their acquire is never enabled. work_progresses above is the weaker, system-level guarantee.

An earlier version of this article claimed per-process progress. Cross-checking the model with Caelum’s bounded model checker and Z3 produced the crash-loop counterexample, which exposed a bug in the fairness handling of Caelum’s explicit-state engine; the engine is now fixed and agrees.

Writing the model required stating every assumption explicitly: only the owner’s host decides whether the holder is dead (A0), acquiring the lock is atomic (A1), processes terminate (A2), an acquire that keeps becoming possible eventually happens (A3), and a crashed process is restarted (A4). If A4 does not hold, the lock remains until an operator removes it; this is the cost of not coordinating.

Result: a simpler implementation

None of the distributed machinery from step 4 is needed. The algorithm is: take the lock atomically; if it is stale and owned by the local host, recover it; otherwise wait.

This illustrates a central use of lightweight formal verification: not only proving that complex code is correct, but showing that the complex code is unnecessary. Once the assumptions that actually hold are written down (host affinity, exact local failure detection, atomic creation), the design reduces from a distributed-systems problem to careful file handling, and the model checker confirms that the reduction is sound.

In short: Small design + strong guarantees. In this case I could fit the implementation in ~200 lines that I know are deadlock and data-corruption free. And this is a solved problem now, I can implement it in any language I want.

Lessons learned

The great value of lightweight formal verification is that it forces you to think rigorously about the properties that must hold in your system, which in turn forces you to think rigorously about what assumptions must be true for those properties to follow, which in turn forces you to enumerate all your assumptions. And once you enumerate them, you can find out, with a simple Google search or a question to an LLM, whether they hold in your production environment. For example, that /etc/machine-id may not be unique.

The full specification, with explanations and a Check button: NFS Shared Lock — Caelum real-world examples.
